OPERA300FCP – Profile LED Engine (300W RGBALC)

Description

Overview

• 300W RGBALC LED profile fixture
• Designed for theatre, stage, and projection lighting
• Includes gobo holder
• Supports True1 power + 3 & 5-pin DMX connections

Photometrics (Light Output & Optics)

• Light source: 300W RGBALC LED
• CRI: up to 97 (high color accuracy)
• Beam angles:
  • Fixed: 14°, 19°, 26°, 36°, 50°
  • Zoom lens options: 18°–36°, 25°–50°
• Colour temperature: 2700K – 10,000K adjustable
• PWM: 1,000 – 8,000 Hz (flicker control)
• LED lifespan: ~50,000 hours
• Optional lenses: PSLII series (various focal lengths)

Photometrics (Light Output & Optics)

• Light source: 300W RGBALC LED
• CRI: up to 97 (high color accuracy)
• Beam angles:
  • Fixed: 14°, 19°, 26°, 36°, 50°
  • Zoom lens options: 18°–36°, 25°–50°
• Colour temperature: 2700K – 10,000K adjustable
• PWM: 1,000 – 8,000 Hz (flicker control)
• LED lifespan: ~50,000 hours
• Optional lenses: PSLII series (various focal lengths)

Power

• Power supply: 100–240V AC, 50/60Hz
• Power consumption: 300W
• Connector: True1 in/out

Control

• Modes: DMX, RDM, Manual
• Protocol: DMX512
• DMX channels: 9 / 10 / 7H / 8H / 17H
• Connections: 3-pin & 5-pin XLR
• Display: 4-button OLED panel

Build & Physical

• Housing: Die-cast aluminum (matte black)
• Tilt: ±90°
• Cooling: Silent fan + intelligent temp control
• IP rating: IP23
• Weight: ~10 kg
• Dimensions: 538 × 270 × 395 mm
• Includes:
  • Gobo holder
  • Mounting bolts

Key Use Cases

• Theatre profile lighting
• Projection with gobos
• Precise beam shaping and edge control
• Color-accurate stage lighting

Simple takeaway

Compared to the FCF (Fresnel version), this is a profile fixture, meaning:

• sharper beam edges
• supports gobos and shaping
• more precise control for theatrical setups
